Presses for the Progressive Die Industry

OAK Press Solutions Inc. presses feature large die areas, superior slide guidance, and heavy-duty cast iron frame construction for superior adaptability, accuracy, and attenuation of shock and vibration.

The four-point connection system on the CP Series provides the following benefits:

• Greatly increased off-center loading capacity
• Simplified tooling designs
• Capacity to run large progressive tools in either direction (F-B or L-R)
• Evenly distributed punching force across entire slide face

The patented scotch yoke slide of the LP Series press includes a total of twelve preloaded roller bearing assemblies.

• Eight bearing assemblies are installed near the material pass line to ensure the lateral positioning of the slide.
• Four additional bearing assemblies are installed above the drive shaft to counteract the effects of tipping forces created by tooling.

OAK Press Solutions Inc. presses provides up to twelve inches of slide lift which greatly simplifies:

• Material lacing (you can open die area without affecting shut height settings)
• Tooling Inspection and maintenance
• Replacing tooling sections without removing die from press resulting in less downtime

• Powerful hydraulic withdrawal system can “unstick” even severe jambs
• No need to “bar” the press, reverse the drive motor, or loosen tie rods
• Recover from slide stalls in seconds instead of hours

Withdrawal system powerful enough to lift the entire die set off the bolster.
